Sony/Philips Digital Interface Registers
Left Channel Status for Subframe A
Register (DIRCHANL)
This register (
DIRCHANL
register located at address 0x24AA.
Table A-40. DIRCHANL Register
Bit
7–0
15–8
23–16
31–24
Right Channel Status for Subframe B
Register (DIRCHANR)
This register (
DIRCHANR
register located at address 0x24AB.
Table A-41. DIRCHANR Register
Bit
7–0
15–8
23–16
31–24
A-96
, described in
Name
DIR_B1CHANL
DIR_B2CHANL
DIR_B3CHANL
DIR_B4CHANL
, described in
Name
DIR_B1CHANR
DIR_B2CHANR
DIR_B3CHANR
DIR_B4CHANR
ADSP-21368 SHARC Processor Hardware Reference
Table
A-40) is a 32-bit, read/write
Description
Channel status byte 1 for subframe A
Channel status byte 2 for subframe A
Channel status byte 3 for subframe A
Channel status byte 4 for subframe A
Table
A-41) is a 32-bit, read/write
Description
Channel status byte 1 for subframe B
Channel status byte 2 for subframe B
Channel status byte 3 for subframe B
Channel status byte 4 for subframe B
