Analog Devices SHARC ADSP-21368 Hardware Reference Manual page 241

SRU_PIN4 (0x2464)
Reserved
DAI_PB20_I
DAI Pin Buffer 20 Input
DAI_PB19_I
DAI Pin Buffer 19 Input
DAI_PB18_I
DAI Pin Buffer 18 Input
Figure 4-34. SRU_PIN4 Register
Table 4-7. Group D Sources—Pin Signal Assignments
Selection Code
0000000 (0x0)
0000001 (0x1)
0000010 (0x2)
0000011 (0x3)
0000100 (0x4)
0000101 (0x5)
0000110 (0x6)
0000111 (0x7)
0001000 (0x8)
0001001 (0x9)
0001010 (0xA)
0001011 (0xB)
0001100 (0xC)
ADSP-21368 SHARC Processor Hardware Reference
Digital Audio/Digital Peripheral Interfaces
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0 0 0 0 0 1 0
15 14 13 12 11 10 9 8
0 1 0 0 1 1 1 1
Source Signal
DAI_PB01_O
DAI_PB02_O
DAI_PB03_O
DAI_PB04_O
DAI_PB05_O
DAI_PB06_O
DAI_PB07_O
DAI_PB08_O
DAI_PB09_O
DAI_PB10_O
DAI_PB11_O
DAI_PB12_O
DAI_PB13_O
1 0 1 1 0 1 0 0
7 6 5 4 3 2 1
1 0 0 1 1 1 1
Description (Source)
Select DAI pin buffer 1
Select DAI pin buffer 2
Select DAI pin buffer 3
Select DAI pin buffer 4
Select DAI pin buffer 5
Select DAI pin buffer 6
Select DAI pin buffer 7
Select DAI pin buffer 8
Select DAI pin buffer 9
Select DAI pin buffer 10
Select DAI pin buffer 11
Select DAI pin buffer 12
Select DAI pin buffer 13
Reset = 0x05694F9E
1
DAI_PB19_I
DAI Pin Buffer 19 Input
0
0
DAI_PB17_I
DAI Pin Buffer 17 Input
4-39
