Right Channel Status for Subframe B
Registers (DITCHANBx)
There are six channel status buffer registers associated with subframe B.
These registers are listed with their locations in
Table A-35. DITCHANBx Registers
Register (Address)
DITCHANB0 (0x24A2)
DITCHANB1 (0x24DA)
DITCHANB2 (0x24DB)
DITCHANB3 (0x24DC)
DITCHANB4 (0x24DD)
DITCHANB5 (0x24DE)
User Bits Buffer Registers for Subframe A
Registers (DITUSRBITAx)
There are six user bits buffer registers associated with subframe A (left
channel). These registers are listed with their locations in
Table A-36. DITUSRBITAx Registers
Register (Address)
DITUSRBITA0 (0x24E0)
DITUSRBITA1 (0x24E1)
DITUSRBITA2 (0x24E2)
DITUSRBITA3 (0x24E3)
DITUSRBITA4 (0x24E4)
DITUSRBITA5 (0x24E5)
A-90
Bits 7–0 Bits 15–8
BYTE1 BYTE2
BYTE5 BYTE6
BYTE9 BYTE10
BYTE13 BYTE14
BYTE17 BYTE18
BYTE21 BYTE22
Bits 7–0 Bits 15–8
BYTE0 BYTE1
BYTE4 BYTE5
BYTE8 BYTE9
BYTE12 BYTE13
BYTE16 BYTE17
BYTE20 BYTE21
ADSP-21368 SHARC Processor Hardware Reference
Table A-35.
Bits 23–16 Bits 31–24
BYTE3 BYTE4
BYTE7 BYTE8
BYTE11 BYTE12
BYTE15 BYTE16
BYTE19 BYTE20
BYTE23 Reserved
Table A-36.
Bits 23–16 Bits 31–24
BYTE2 BYTE3
BYTE6 BYTE7
BYTE10 BYTE11
BYTE14 BYTE15
BYTE18 BYTE19
BYTE22 BYTE23
