Analog Devices SHARC ADSP-21368 Hardware Reference Manual page 265

Table 4-13. Group C Signals (Cont'd)
Binary Decimal
001101 13
001110 14
001111 15
010000 16
010001 17
010010 18
010011 19
010100 20
010101 21
010110 22
010111 23
011000 24
011001 25
011010 26
011011 27
011100 28
011101 29
011110 30
011111 31
100000 32
100001 33
100010 34
100011 35
100100 36
ADSP-21368 SHARC Processor Hardware Reference
Digital Audio/Digital Peripheral Interfaces
Signal
SPIFLG0_PE_O
SPIFLG1_PE_O
SPIFLG2_PE_O
SPIFLG3_PE_O
SPIBMISO_PE_O
SPIBMOSI_PE_O
SPIBCLK_PE_O
SPIBFLG0_PE_O
SPIBFLG1_PE_O
SPIBFLG2_PE_O
SPIBFLG3_PE_O
FLAG4_PE_O
FLAG5_PE_O
FLAG6_PE_O
FLAG7_PE_O
FLAG8_PE_O
FLAG9_PE_O
FLAG10_PE_O
FLAG11_PE_O
FLAG12_PE_O
FLAG13_PE_O
FLAG14_PE_O
FLAG15_PE_O
TWI_SDATA_OE
Description
Pin enable for slave select 0 from SPI
Pin enable for slave select 1 from SPI
Pin enable for slave select 2 from SPI
Pin enable for slave select 3 from SPI
Pin enable for MISO from SPIB
Pin enable for MOSI from SPIB
Pin enable for CLK from SPIB
Pin enable for slave select 0 from SPIB
Pin enable for slave select 1 from SPIB
Pin enable for slave select 2 from SPIB
Pin enable for slave select 3 from SPIB
Pin enable for Flag 4 output
Pin enable for Flag 5 output
Pin enable for Flag 6 output
Pin enable for Flag 7 output
Pin enable for Flag 8 output
Pin enable for Flag 9 output
Pin enable for Flag 10 output
Pin enable for Flag 11 output
Pin enable for Flag 12 output
Pin enable for Flag 13 output
Pin enable for Flag 14 output
Pin enable for Flag 15 output
Serial data output enable from TWI
4-63
