Table B-4. LIRPTL Register Bit Descriptions (Cont'd)
Bit Name
19 P18IMSK
(SPIBMSK)
20 P6IMSKP
(SP0IMSKP)
21 P7IMSKP
(SP2IMSKP)
22 P8IMSKP
(SP4IMSKP)
23 P9IMSKP
(EPDMA0IMSKP)
24 P10IMSKP
(GPTMR1MSKP)
25 P11MSKP
26 P12IMSKP
(DAI2IMSKP)
ADSP-21368 SHARC Processor Hardware Reference
Description
Programmable Interrupt Mask 18 (SPI Interrupt Mask Sec-
ondary SPI Port). Unmasks the SPIB interrupt (if set, = 1),
or masks the SPIB interrupt (if cleared, = 0).
Programmable Interrupt Mask Pointer 9 (SPORT0 Inter-
rupt Mask Pointer). When the processor is servicing another
interrupt, this bit indicates if the SP0I interrupt is unmasked
(if set, = 1), or the SP0I interrupt is masked (if cleared, = 0).
Programmable Interrupt Mask Pointer 7 (SPORT2 Inter-
rupt Mask Pointer). When the processor is servicing another
interrupt, this bit indicates if the SP2I interrupt is unmasked
(if set, = 1), or the SP2I interrupt is masked (if cleared, = 0).
Programmable Interrupt Mask Pointer 8 (SPORT4 Inter-
rupt Mask Pointer). When the processor is servicing another
interrupt, this bit indicates if the SP4I interrupt is unmasked
(if set, = 1), or the SP4I interrupt is masked (if cleared, = 0).
Programmable Interrupt Mask Pointer 9 (External Port
DMA Channel 0 Interrupt Mask Pointer). When the pro-
cessor is servicing another interrupt, this bit indicates if the
EPDMA0 interrupt is unmasked (if set, = 1), or masked (if
cleared, = 0).
Programmable Interrupt Mask Pointer 10 (General-Pur-
pose IOP Timer 1 Interrupt Mask Pointer).
When the processor is servicing another interrupt, this bit
indicates if the GPTMR1I interrupt is unmasked (if set, = 1),
or the GPTMR1I interrupt is masked (if cleared, = 0).
Programmable Interrupt Mask Pointer 11 (SPORT7 Inter-
rupt Mask Pointer). When the processor is servicing another
interrupt, this bit indicates if the SP7I interrupt is unmasked
(if set, = 1), or the SP7I interrupt is masked (if cleared, = 0).
Programmable Interrupt Mask Pointer 12 (DAI Low Prior-
ity Interrupt Mask Pointer).
When the processor is servicing another interrupt, this bit
indicates if the DAI2I is unmasked (if set, = 1), or masked (if
cleared, = 0).
