DAI_IRPTL_RE
rising and falling edges, respectively. For more information on these regis-
ters, see
"DAI Interrupt Controller Registers" on page
Programs can manage responses to signals by configuring registers. In a
sample audio application, for example, upon detection of a change of pro-
tocol, the output can be muted. This change of output and the resulting
behavior (causing the sound to be muted) results in an alert signal (an
interrupt) being introduced in response (if the detection of a protocol
change is a high priority interrupt).
The
DAI_IRPTL_FE
on the falling edge.
Use of the
DAI_IRPTL_RE
notice and respond to rising edges, falling edges, both rising and falling
edges, or neither rising nor falling edges so they can be masked separately.
Responses to changes in conditions of signals (including changes in DMA
state, introduction of error conditions, and so on) can only be enabled
using the
DAI_IRPTL_RE
Configuring Peripherals Using SRU1
The following sections describe how the various peripherals associated
with SRU1 are configured.
Configuring the SPORTs
The serial port chapter provides the signal sensitivity information of the
SPORT signals which needs to be considered while configuring the serial
ports using DAI pins.
tivity" on page 5-9.
ADSP-21368 SHARC Processor Hardware Reference
Digital Audio/Digital Peripheral Interfaces
or
registers enables the interrupt level on the
DAI_IRPTL_FE
register can only be used for latching interrupts
or
DAI_IRPTL_FE
register.
For more information, see "Serial Port Signal Sensi-
A-112.
registers allows programs to
4-71
