Making Connections in the SRUs
Table 4-12. Group B Signals (Cont'd)
Binary Decimal
000011 03
000100 04
000101 05
000110 06
000111 07
001000 08
001001 09
001010 10
001011 11
001100 12
001101 13
001110 14
001111 15
010000 16
010001 17
010010 18
010011 19
010100 20
010101 21
010110 22
010111 23
011000 24
011001 25
011010 26
4-58
Signal
DPI_P02_O
DPI_P03_O
DPI_P04_O
DPI_P05_O
DPI_P06_O
DPI_P07_O
DPI_P08_O
DPI_P09_O
DPI_P10_O
DPI_P11_O
DPI_P12_O
DPI_P13_O
DPI_P14_O
TIMER0_O
TIMER1_O
TIMER2_O
UART0_TX_O
UART1_TX_O
SPI_MISO_O
SP_IM0SI_O
SPI_CLK_O
SPI_FLG0_O
SPI_FLG1_O
SPI_FLG2_O
ADSP-21368 SHARC Processor Hardware Reference
Description
External pin 2
External pin 3
External pin 4
External pin 5
External pin 6
External pin 7
External pin 8
External pin 9
External pin 10
External pin 11
External pin 12
External pin 13
External pin 14
Timer0 output
Timer1 output
Timer2 output
UART0 transmitter output
UART1 transmitter output
MISO from SPI
MOSI from SPI
Clock output from SPI
Slave select 0 from SPI
Slave select 1 from SPI
Slave select 2 from SPI
