Making Connections in the SRUs
Table 4-7. Group D Sources—Pin Signal Assignments (Cont'd)
Selection Code
0001101 (0xD)
0001110 (0xE)
0001111 (0xF)
0010000 (0x10)
0010001 (0x11)
0010010 (0x12)
0010011 (0x13)
0010100 (0x14)
0010101 (0x15)
0010110 (0x16)
0010111 (0x17)
0011000 (0x18)
0011001 (0x19)
0011010 (0x1A)
0011011 (0x1B)
0011100 (0x1C)
0011101 (0x1D)
0011110 (0x1E)
0011111 (0x1F)
0100000 (0x20)
0100001 (0x21)
0100010 (0x22)
0100011 (0x23)
0100100 (0x24)
4-40
Source Signal
DAI_PB14_O
DAI_PB15_O
DAI_PB16_O
DAI_PB17_O
DAI_PB18_O
DAI_PB19_O
DAI_PB20_O
SPORT0_DA_O
SPORT0_DB_O
SPORT1_DA_O
SPORT1_DB_O
SPORT2_DA_O
SPORT2_DB_O
SPORT3_DA_O
SPORT3_DB_O
SPORT4_DA_O
SPORT4_DB_O
SPORT5_DA_O
SPORT5_DB_O
SPORT0_CLK_O
SPORT1_CLK_O
SPORT2_CLK_O
SPORT3_CLK_O
SPORT4_CLK_O
ADSP-21368 SHARC Processor Hardware Reference
Description (Source)
Select DAI pin buffer 14
Select DAI pin buffer 15
Select DAI pin buffer 16
Select DAI pin buffer 17
Select DAI pin buffer 18
Select DAI pin buffer 19
Select DAI pin buffer 20
Select SPORT 0A data
Select SPORT 0B data
Select SPORT 1A data
Select SPORT 1B data
Select SPORT 2A data
Select SPORT 2B data
Select SPORT 3A data
Select SPORT 3B data
Select SPORT 4A data
Select SPORT 4B data
Select SPORT 5A data
Select SPORT 5B data
Select SPORT 0 clock
Select SPORT 1 clock
Select SPORT 2 clock
Select SPORT 3 clock
Select SPORT 4 clock
