121-339 Price Table Error RAP

117-339 EPA unit price table error.
Procedure
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Advise the customer to correct the unit price settings in the coin kit. Switch off, then switch
on the machine, GP 10.
2. If the fault persists:
a. Ensure that all connectors on the drive PWB,
3.10 Item 6 are securely connected. Ensure all surface mounted modules on both
PWBs are securely connected.
b. Reload the software, GP 4.
c. If the fault persists, install a new ESS PWB,
Launch Issue
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
WARNING
PL 1.10 Item 3 and the ESS PWB,
PL 3.10 Item 6.
121-340 EP Accessory MisMatch RAP
117-340 The combination of accessories that are installed does not match the specifications.
Procedure
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Make any accessories are installed correctly and are the correct specification.
2. Switch off, then switch on the machine,
3. Ensure that all connectors on the drive PWB,
PL Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
4. Reload the software, GP 4.
5. If the fault persists, install a new ESS PWB,
April 2017
2-553
WARNING
GP 10. Disconnect the power cord. Electricity can cause
GP 10.
PL 1.10 Item 3 and the ESS PWB,
PL 3.10 Item 6.
Status Indicator RAPs
121-339, 121-340
PL 3.10
