5 In the Label Style Composer dialog box, on the Information tab, specify
the following parameters:
Name: Design Speeds - Inline
Description: Small design speed label perpendicular to the alignment
6 Click the General tab.
On the General tab, you can specify the settings for the overall label style,
including the visibility, layer, and plan readability. For this exercise,
accept the default settings on this tab. You can turn on or off the visibility
of the individual label components on either the Summary or Layout
tab.
7 Click the Layout tab.
On the Layout tab, you specify the content of the label style. A label can
be made up of one or more components, each of which can have separate
properties.
8 Examine the contents of the Component Name list.
Each component is shown in the Preview pane on the right side of the
dialog box. You can use the buttons to the right of the Component Name
list to create, copy, or delete label style components. These components
were copied when you created the style from the existing Station Over
Speed style.
9 In the Component Name list, select Station. In the General collection,
change the Visibility to False.
Notice that your change is shown immediately in the Preview pane. This
pane is useful when you are designing a label style. If you do not like
what you see in the preview, you can change it before saving the style.
NOTE To delete the Station component, select it from the Component Name
list, and then click
10 In the Component Name list, select Design Speed. Specify the following
parameters:
General
Anchor Component: Line
Anchor Point: End
