Tutorial: Working With Data Bands - Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual

W-E Pipe - (2)
W-E Structure - (1)
W-E Structure - (2)
21 In the Select Stacked View To Specify Options For list, select Top View.
22 In the Select Pipe Networks To Draw In Profile View list, select the Select
check box.
23 Clear all check boxes except for the following parts:
W-E Pipe - (1)
W-E Pipe - (2)
W-E Structure - (1)
W-E Structure - (2)
24 Click Create Profile View.
25 In the drawing, pan to the clear area at the right of the surface. Click to
place the profile views.
26 In Toolspace, on the Prospector tab, expand the Alignments
North-South
Notice that three separate profile views were created.
To continue to the next tutorial, go to
(page 330).

Tutorial: Working with Data Bands

This tutorial demonstrates how to add and change the appearance of data
bands in a profile view.
Data bands can be placed at either the top or bottom of the profile view to
annotate profile station and elevation data, vertical or horizontal geometry
points, and so on. Data bands can be added to a profile view either as a set or
individually.
NOTE Data bands are also used with section views. The tasks you will learn in the
following exercises can be applied to profile views and section views.
330 | Chapter 9 Profiles Tutorials
Profile Views collection.
Tutorial: Working with Data Bands
Road:
