On this page, you specify the base point from which the survey network
will be moved.
3 Click Next.
On the Rotation Angle page, you specify the base point from which the
survey network will be moved. For this exercise, you will not change the
rotation of the survey network.
4 On the Rotation Angle page, for Rotation Angle, enter 0.
5 Click Next.
On the Destination Point page, you specify the point to which the survey
network will be moved. Notice that you can specify a new Easting,
Northing, or Elevation Change value. In this exercise, you will change
only the elevation.
6 On the Destination Point page, for Elevation Change, enter -2.25.
7 Click Next.
On the Summary page, you can examine the results of the translation
before it is applied to the survey network. If you want to modify the
translation, you can use the Back button to return to previous pages on
the wizard.
8 Click Finish.
9 In Toolspace, on the Survey tab, click the Setups collection.
In the list view, examine the elevation values of the setups that you
examined in Step 2. Notice that the values have been decreased by 2.25.
Station Point 1, Backsight Point 1000: Instrument Elevation = 261.400
Station Point 2, Backsight Point 1: Instrument Elevation = 257.710
Station Point 3, Backsight Point 2: Instrument Elevation = 255.188
To continue to the next tutorial, go to
155).
Tutorial: Manually Creating Survey Data
This tutorial demonstrates how to manually create and add survey data.
Manually Creating Survey Data
Tutorial: Manually Creating Survey Data | 155
