Exercise 4: Editing an Offset Widening

In this exercise, you will change the transition between an offset alignment
and its widening region, and then use grips to modify the widening geometry.
For more information, see the AutoCAD Civil 3D Help topic Editing Offset
Alignments and Widenings.
This exercise continues from
Alignment
Change the widening transition
1 Open Align-6D.dwg, which is located in the
819).
The drawing contains a surface and a centerline alignment with two offset
alignments. The offset alignment on the right-hand side of the centerline
alignment has two widening regions.
2 Select the offset alignment that is on the right-hand side of the centerline
alignment. Right-click. Click Edit Offset Parameters.
In the Offset Alignment Parameters dialog box, notice that the offset
alignment is divided into a series of regions and transitions. Each region
represents the offset values of the sequential station ranges along the
centerline alignment. The transitions represent the geometry that joins
one region to the next.
NOTE The parameters for the first region are displayed in the window. Show
the parameters for subsequent regions by using the Select Widening Region
list or the arrow buttons.
3 In the Offset Alignment Parameters dialog box, click
4 In the Property column, select each of the Region and Transition entries
in turn.
Notice that each region and transition is highlighted in the drawing as
you select it.
5 Expand the Transition Out category.
6 Change the Transition Type from Linear to Curve-Line-Curve.
The transition changes to a line with a curve on either end.
Exercise 3: Adding a Widening to an Offset
(page 239).
Exercise 4: Editing an Offset Widening | 243
tutorial drawings folder (page
.
