6 In Toolspace, on the Prospector tab, expand the
Offset Alignments collection.
Notice that the two alignments you created were placed in the Offset
Alignments collection. You can create profiles, profile views, and sample
line groups from offset alignments, just as you can for standard, Centerline
alignments.
To continue this tutorial, go to
236).

Exercise 2: Editing an Offset Alignment

In this exercise, you will examine the offset alignment editing tools.
The geometry editing tools that are available for an offset alignment depend
on whether the alignment is static or dynamic. If the offset alignment is
dynamically linked to the parent centerline alignment, then you cannot edit
the offset alignment geometry. If the offset alignment is static, then you can
use the tools on the Alignment Layout Tools toolbar.
An Offset Parameters tab is available in the Alignment Properties dialog box.
From this location, you can change parameters such as nominal offset value
and start and end stations.
For more information, see the AutoCAD Civil 3D Help topic Editing Offset
Alignments and Widenings.
This exercise continues from
Examine the offset alignment geometry
1 Open Align-6B.dwg, which is located in the
819).
The drawing contains a surface and a centerline alignment with two offset
alignments.
2 Select the left offset alignment.
236 | Chapter 8 Alignments Tutorials
Exercise 2: Editing an Offset Alignment
Exercise 1: Creating Offset Alignments
tutorial drawings folder
Alignments
(page
(page 233).
(page
