Specify parcel creation settings
1 Open Parcel-1D.dwg, which is available in the
819).
2 Click Home tab
Creation Tools
3 On the Parcel Layout Tools toolbar, click
4 Specify the following parameters:
As you specify each parameter, notice that a preview graphic is displayed
at the bottom of the Parcel Layout Tools window.
Parcel Sizing
Minimum Area: 8000.00
Minimum Frontage: 40.0000
Use Minimum Frontage At Offset: Yes
Frontage Offset: 20.0000
Minimum Width: 40.0000
Minimum Depth: 50.0000
Use Maximum Depth: Yes
Maximum Depth: 200.0000
Multiple Solution Preference: Use Smallest Area
Automatic Layout
Automatic Mode: Off
Remainder Distribution: Place Remainder In Last Parcel
Create parcels using a swing line
1 On the Parcel Layout Tools toolbar, click
2 In the Create Parcels – Layout dialog box, for Parcel Style, select
Single-Family. Leave other settings at their default values. Click OK.
356 | Chapter 10 Parcels Tutorials
Create Design panel
.
tutorial drawings folder
Parcel drop-down Parcel
.
Swing Line – Create.
(page
