Label multiple alignment segments
NOTE This exercise uses Labels-2a.dwg with the modifications you made in the
previous exercise.
1 Click Annotate tab
menu Alignment
2 In the Add Labels dialog box, specify the following parameters:
Feature: Alignment
Label Type: Multiple Segment
3 In the three label style fields, accept the default styles.
You can choose specific styles for each of the Line, Curve, and Spiral label
styles. This alignment does not contain any spirals, so the Spiral Label
Style setting is ignored.
4 Click Add.
5 On the left-hand side of the site, click the West Street alignment, which
you created in Exercise 1: Adding Labels in Groups
The Multiple Segment label command places a label at the middle of each
line and curve. This method can be convenient, but sometimes a few of
the labels overlap other features of the drawing. In
and Moving Labels
Label single alignment segments
1 In the Add Labels dialog box, specify the following parameters:
Feature: Alignment
Label Type: Single Segment
Line Label Style: Line Label Style
NOTE Notice that you can use either a General Line Label Style or Alignment
Line Label Style. General Line and Curve label styles can be applied to lines
and curves that are part of an Alignment or Parcel object.
2 Click Add.
Labels & Tables panel
Add Alignment Labels
(page 755), you will move some of these labels.
Alignment Name
Exercise 2: Manually Labeling an Object | 753
Add Labels
.
(page 745).
Exercise 3: Selecting
