2 Click Home tab
Creation Tools
3 On the Parcel Layout Tools toolbar, click
4 Specify the following parameters:
As you specify each parameter, notice that a preview graphic is displayed
at the bottom of the Parcel Layout Tools window.
Parcel Sizing
Minimum Area: 8000.00
Minimum Frontage: 40.0000
Use Minimum Frontage At Offset: No
Frontage Offset: 20.0000
Minimum Width: 40.0000
Minimum Depth: 50.0000
Use Maximum Depth: Yes
Maximum Depth: 200.0000
Multiple Solution Preference: Use Shortest Frontage
Automatic Layout
Automatic Mode: Off
Remainder Distribution: Place Remainder In Last Parcel
Swing one end of a parcel lot line
1 On the Parcel Layout Tools toolbar, click
2 In the Create Parcels – Layout dialog box, click OK.
You are prompted to select the attached lot line to adjust.
3 In the drawing, click the lot line that is between parcel 104 and parcel
105.
4 Select the parcel to adjust by moving the cursor over property 104 and
clicking. Notice that the parcel borders are highlighted.
Exercise 2: Swinging One End of a Parcel Lot Line | 369
Create Design panel
.
Parcel drop-down Parcel
.
Swing Line – Edit.
