2 Change the Spiral Out Length Value to 33.000m. Press Enter.
3 Change the Curve Radius Value to 100.000m. Press Enter.
The
from the Alignment Entities vista.
Notice that the warning symbol is still displayed on all the curve
sub-entity. The curve still violates the design check. To clear the warning
symbols, all sub-entities in the group must meet the values specified in
both the design criteria file and the applicable design checks.
4 In the Alignment Entities vista, in row 2.2, examine the Length column.
Notice that the Length value is less than the value of 40 that is specified
by the design check. Notice that you cannot edit the Length value for
this type of curve. However, you can increase the curve radius to increase
the curve length.
5 In row 2.2, change the Radius value to 200.000m. Press Enter.
6 In the Alignment Entities vista, select row 4. In the Length column,
change the value to 40.000m. Press Enter.
To continue this tutorial, go to
256).

Exercise 3: Working with Design Checks

In this exercise, you will create an alignment design check, add the design
check to a design check set, and then apply the design check set to an
alignment.
To create a design check, you set up a mathematical formula, using existing
alignment sub-entity properties. The complexity of design check formulas can
vary greatly. In this exercise, you will create a relatively simple design check
that validates whether the tangent length meets a minimum value at a given
design speed.
NOTE The processes for creating design checks for alignments and profiles are
very similar. The basic workflow that is demonstrated in this exercise can be used
for both alignment and profile design checks.
For more information, see Alignment Design Checks.
256 | Chapter 8 Alignments Tutorials
warning symbol is cleared from the Curve Radius row, as well as
Exercise 3: Working with Design Checks (page
