Major station label type style changed: STA: 0+060 only
To continue this tutorial, go to
to Another Object
Exercise 6: Creating a Label Style that Refers to Another
Object
In this exercise, you will use the reference text component to create a single
label style that annotates two objects of different types.
The Reference Text label component is used to annotate multiple types of
objects with a single label. You can insert references to surfaces, profiles,
parcels, and alignments. Each reference text component can refer to only one
AutoCAD Civil 3D object. If you need a label style to refer to several objects,
create a separate reference text component for each referenced object.
In this exercise, you will create a label style that displays the alignment station
and surface elevation at each horizontal geometry point.

Exercise 6: Creating a Label Style that Refers to Another Object | 797

Exercise 6: Creating a Label Style that Refers
(page 797).
