4 Click Compute.
5 In the Quantity Takeoff Report dialog box, in the drop-down menu, select
Detailed Linear (HTML).xsl.
Examine the report. The length, station, and offset of the start and end
of each pipe is displayed in this report.
6 In the drop-down menu, select Detailed Count (HTML).xsl.
The baseline, station value, and offset of the object to which each pay
item is assigned is displayed for each pay item instance.
Notice that several instances of Pay Item 60409-0500 are 17 feet on either
side of the alignment. This indicates that these inlets are placed along
the edges of pavement of the Side Road corridor.
Insert a quantity takeoff report into the drawing
1 Click Draw.
2 Pan to an empty space in the drawing.
3 Click the place the table.
The drawing zooms to the quantity takeoff report, which is in an
AutoCAD table.
Exercise 5: Working with Quantity Reports | 621
