Earthwork and material volumes are calculated by comparing two surfaces to
each other. You can calculate quantities between sample lines derived from
regular surface models and from corridor surfaces.
User-definable tables specify which materials are defined by which surfaces,
and the characteristics of these materials. Finally, average end area analysis is
used to tabulate the material quantities along the corridor.
For more information, see the AutoCAD Civil 3D Help topic Analyzing Sectional
Volumes.
Exercise 1: Reviewing Quantity Takeoff Criteria and
Report Settings
In this exercise, you will review the options that are available for quantity
takeoff criteria and reports.
The quantity takeoff report settings include the default quantity takeoff criteria
used to create material lists and default styles for tables. The quantity takeoff
criteria includes a list of materials that specifies the surfaces and shapes from
which you want to generate volume information.
For more information, see the AutoCAD Civil 3D Help topic Creating Quantity
Takeoff Criteria.
Review quantity takeoff settings
1 Open Earthworks-1.dwg, which is located in the
(page 819).
The drawing opens, displaying three viewports.
2 In Toolspace, on the Settings tab, expand Quantity Takeoff
Commands.
3 Under the Commands collection, double-click GenerateQuantitiesReport
to display the Edit Command Settings dialog box.
4 Browse through the various settings available, but do not change any
settings. When finished, click Cancel.
Examine the quantity takeoff criteria
1 In Toolspace, on the Settings tab, expand Quantity Takeoff
Takeoff Criteria.
Three styles are defined in the collection.
590 | Chapter 16 Material Calculation Tutorials
tutorial drawings folder
Quantity
