Exercise 3: Generating a Volume Report

In this exercise, you will use the Earthworks criteria to generate a quantity
takeoff report.
For more information, see the AutoCAD Civil 3D Help topic Analyzing Sectional
Volumes.
This exercise continues from
Generate a volume report
1 Open Earthworks-2.dwg, which is located in the
(page 819).
The drawing opens, displaying three viewports.
2 Click Analyze tab
3 In the Report Quantities dialog box, specify the following parameters:
Select Alignment: Centerline (1)
Select Sample Line Group: SLG-1
Select A Material List: Material List - (1)
This is the material list you created in
List
group using the Earthworks criteria.
Select A Style Sheet: Earthwork.xsl
Display XML Report: Selected
4 Click OK.
5 The report is displayed.
The Cut Volume is the area of material in cut, multiplied by the Cut
Factor defined in the quantity takeoff criteria. The Fill Volume is the area
of fill material multiplied by the Fill Factor.
The areas for each material are averaged between stations and multiplied
by the station difference to produce the incremental volumes. These
volumes are added from station to station to produce the cumulative
volumes.
Exercise 3: Generating a Volume Report
Exercise 2: Creating a Material List
Volumes And Materials panel
(page 591) by calculating volume quantities for the sample line
Exercise 3: Generating a Volume Report | 593
(page 591).
tutorial drawings folder
Volume Report.
Exercise 2: Creating a Material
(page
