5 In the Properties palette, under ADVANCED, specify the following
parameters:
Side: Right
Default Width: 14.0000
Depth: 1.0000
Transition: Change Offset And Elevation
6 In the drawing, click the marker point on the assembly baseline.
A lane is drawn, extending 14 feet to the right, with a slope of -2% and
a depth of 1 foot.
Add a curb and gutter subassembly
1 In the tool palette, click
2 In the Properties palette, under ADVANCED, specify the following
parameters:
Side: Right
Gutter Width: 1.2500
3 In the drawing, click the marker point at the top-right edge of the lane
to draw the curb and gutter.
Add a sidewalk subassembly
1 In the tool palette, click
2 In the Properties palette, under ADVANCED, specify the following
parameters:
Side: Right
Buffer Width 1: 2.0000
Buffer Width 2: 3.0000
3 In the drawing, click the marker point at the top back-side of the curb to
add the sidewalk and its buffer zones.
Exercise 1: Creating an Assembly with a Transition Lane | 465
BasicCurbAndGutter.
BasicSidewalk.
