7 For SE - Quadrant, select the Widen Turn Lane For Incoming Road check
box.
8 Click Next.
9 For SW - Quadrant, select the Widen Turn Lane For Outgoing Road check
box.
10 Click Next.
11 For NW - Quadrant, select the Widen Turn Lane For Incoming Road check
box.
12 Click OK.
13 In the Create Intersection wizard, make sure that the Create Offset And
Curb Return Profiles check box is selected.
14 Click Next.
Specify the corridor parameters
1 On the Corridor Regions page, specify the following options:
Create Corridors In The Intersection Area: Selected
Create A New Corridor: Selected
Select Surface To Daylight: Existing Ground
2 In the Select Assembly Set File dialog box, navigate to the
folder (page 819).
3 Select _Autodesk (Metric) Assembly Sets.xml. Click Open.
4 Under Maintain Priority Road Crown, in the Curb Return Fillets row,
click .
You can use the Select An Assembly dialog box to substitute an assembly
with another assembly that is in the current drawing. To save your
changes as a new assembly set, click Save As Set on the Corridor Regions
page. For this exercise, you will accept the default assembly set.
For more information about managing corridor assemblies, see the
Corridor Assembly Tutorials
5 Click Cancel.
6 Click Create Intersection.
Exercise 2: Creating a Primary Road Intersection with Turn Lanes | 507
(page 421).
Assemblies
