Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 827

For more information, see the AutoCAD Civil 3D Help topic Section Sheet
Production.
This exercise continues from
811).
Open and save the drawing
1 Open Plan Production-Section Sheets-Create.dwg, which is located in the
tutorial drawings folder
The current drawing must be saved before you create section sheets. To
prevent the tutorial drawing from being overwritten, save it to an alternate
location.
2 Click Save As.
3 In the Save Drawing As dialog box, navigate to the
folder (page 819). Click Save.
Create section sheets
1 Click Output tab
2 In the Create Section Sheets dialog box, specify the following basic
parameters:
Select Alignment: Centerline (1)
Sample Line Group Name: SLG-1
Select Section View Group: Section View Group - 1
3 Under Layout Settings, click
You can use the Name Template dialog box to specify a default name for
each of the layouts. In this exercise, you will accept the default layout
name template.
4 Click Cancel.
5 In the Create Section Sheets dialog box, under Sheet Set, make sure that
New Sheet Set is selected.
6 Under Sheet Set File (.DST) Storage Location, click
Exercise 1: Creating Plan and Profile Sheets
(page 819).
Plan Production panel
.
Exercise 2: Creating Section Sheets | 815
(page
My Civil Tutorial Data
Create Section Sheets
.
.
