4 Right-click Survey 1. Click Edit Survey Database Settings.
5 In the Survey Database Settings dialog box, expand the Survey Command
Window property group. Specify the following parameters:
Point Course Echo: Yes
Figure Course Echo: Yes
Point Coordinate Echo: Yes
Figure Coordinate Echo: Yes
Command Echo: Yes
These settings determine what information will be displayed in the Survey
Command Window.
6 Click OK.
Query data using the Survey Command Window
1 On the Survey tab, expand the Networks collection. Right-click Survey
Network 1. Click Survey Command Window.
2 In the Survey Command Window, click View menu
3 In the Enter Point dialog box, enter 1. Click OK.
The drawing zooms to point 1.
4 Click Point Information menu
5 In the Point Information - Inverse Points dialog box, enter:
Start Point: 1
Ahead Point: 2
6 Click OK.
The following information, which describes the location of each point
and the direction and distance between the points, is displayed in the
command output area:
!
! POINT 1 NORTH: 5000.0000
263.6500
!
! Distance: 300.000
!
Inverse Points.
EAST: 5000.0000
Course: N 72-56-33 E
Exercise 1: Querying Survey Data | 149
Zoom To Point.
EL:
