4 Click OK.
To continue this tutorial, go to

Exercise 4: Setting Survey Styles

In this exercise, you will review the survey network styles and create a figure
style.
The survey network and figure styles control the way that survey features are
displayed in the drawing.
For more information, see the AutoCAD Civil 3D Help topic Survey Styles and
Display.
This exercise continues from
132).
Review the network style settings
NOTE This exercise uses Survey-1.dwg with the modifications you made in the
previous exercise.
1 In Toolspace, on the Settings tab, expand the Survey
collection.
This collection contains all the existing network styles in the drawing.
2 Right-click the Standard network style. Click Edit.
3 In the Network Style dialog box, click the Components tab.
Notice that you can set different marker styles for known control points,
unknown control points, tolerance error points, and sideshot points.
4 Click OK.
Create a figure style
1 Right-click the Figure Styles collection. Click New.
2 In the Figure Style dialog box, on the Information tab, enter Building for
the figure style name.
3 Click the Display tab.
134 | Chapter 6 Survey Tutorials
Exercise 4: Setting Survey Styles
Exercise 3: Adjusting and Verifying Settings
(page 134).
(page
Network Styles
