Exercise 5: Creating Multiple Profile Views

In this exercise, you will produce a set of profile views to display short,
successive segments of a profile.
Multiple profile views are most useful when you are creating final construction
documents from your design. For best results, design your profile in a single
profile view, then use the plan production tools to create multiple profile
views for plotting or publishing. During the plan production process, you
create sheets that display sections of alignments and profiles.
In this exercise, you will bypass the plan production tools to create multiple
profile views in a currently open drawing. You will use the Create Multiple
Profile Views wizard, which allows you to quickly specify the profile view
properties before you create them. If you access this wizard during the plan
production process, many of the properties are not available because they are
already set in the view frame group.
For more information, see the AutoCAD Civil 3D Help topic Working with
Profile Views.
For a tutorial that demonstrates the plan production tools, go to
Production Tutorials
This exercise continues from
Create multiple profile views
1 Open Profile-5E.dwg, which is located in the
819).
This drawing contains two roads, Maple Road and Oak Road, and a single
profile view of Oak Road.
2 Click Home tab
drop-down
3 In the Create Multiple Profile Views wizard, on the General page, specify
the following parameters:
Select Alignment: Oak Road
Profile View Style: Major Grids
4 Click Next.
5 On the Station Range page, in the Length of Each View box, enter 500.00'.
6 Click Next.
