When you select this option, you can specify a template to use in
structuring your project. This option enables you to structure similar
projects in the same way.
4 In the Project Templates Folder area, click
5 In the Browse For Folder dialog box, navigate to the
Templates folder
This is a typical structure for an AutoCAD Civil 3D project. Folders are
provided for many of the document types that are typical of a civil
engineering project.
6 In the Browse For Folder dialog box, select the
folder
7 In the New Project dialog box, in the Project Template field, select _Sample
Project.
8 Click OK.
9 Under the Projects collection, expand the Tutorial Vault Project collection.
Examine the folders and nodes that were created from the template you
specified in Step 7. For example, the Drawings collection contains folders
in which you can save different types of project drawings. The object
collections will contain data references to AutoCAD Civil 3D objects that
reside in the project drawings.
To continue to the next tutorial, go to
Project Object Data
Tutorial: Creating, Referencing, and Modifying
Project Object Data
In this tutorial, you will add a drawing to the project, create a project surface
and then access the surface from another drawing. You will use the
Surface-3.dwg tutorial drawing as the starting point.
This tutorial continues from the
If you are logged in as Administrator, log out and log in as the first test user,
pred (password: red123). To log out, right-click the Projects collection in
Prospector, Master View, and click Log Out. Then right-click Projects and click
Log In To Vault.
200 | Chapter 7 Project Management Tutorials
(page 819)\_Sample Project folder.
(page 819). Click OK.
(page 200).
Database Setup
.
Civil 3D Project
Civil 3D Project Templates
Creating, Referencing, and Modifying
(page 195) tutorial.
