Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 177

2 In Toolspace, on the Survey tab, right-click Survey Databases. Click New
Local Survey Database.
3 In the New Local Survey Database dialog box, for the name, enter Survey
4. Click OK.
4 In Toolspace, on the Survey tab, right-click the database Survey 4. Click
Edit Survey Database Settings.
5 In the Survey Database Settings dialog box, under Survey Command
Window, specify the following parameters:
Ditto Feature: Yes
Auto Point Numbering: No
Start Point Numbering From: 1
Point Course Echo: Yes
Figure Course Echo: Yes
Point Coordinate Echo: Yes
Figure Coordinate Echo: Yes
Command Echo: Yes
Use Batch File: Yes
Use Output File: Yes
6 Click OK.
Create a survey network
1 In Toolspace, on the Survey tab, expand the Survey 4 database. Right-click
the Networks collection. Click New.
2 In the Network dialog box, for Name, enter Survey Network 4.
3 Click OK.
Enter survey data into the survey command window
1 In Toolspace, on the Survey tab, right-click Survey Network 4. Click Survey
Command Window.
2 In the Survey Command Window, enter the following commands into
the Command line.
Exercise 3: Creating Survey Data Using the Survey Command Window | 165
