12 Right-click Rim
either end of the top side of the outer rectangle.
Click a point to set the location of the dimension. A dimension named
LenA1 is created for the long side of the outer edge of the frame.
13 Repeat these steps for the right side of the outer rectangle.
A dimension named LenA2 is created for the short side of the outer edge
of the frame.
710 | Chapter 18 Part Builder Tutorials
Add Dimension
Distance. Click two points at
