15 Right-click Vertical Axis
that represents the elbow. Click a point to set the location of the
dimension. BdyD1 is added to the arc.
16 Add one final length dimension to the left upper horizontal line segment.
LenA7 is added.
684 | Chapter 18 Part Builder Tutorials
Add Dimension
Diameter. Select the arc
