Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 791

Text
Attachment: Bottom Right
X Offset: 0.0 mm
Y Offset: 1.0 mm
11 In the Text collection, for the Contents property, click the Value column.
Click .
You can use the Text Component Editor dialog box to define the content
and format of a label style text component. The Properties list displays
the available properties that can be displayed in a label component. When
you select a component from the list, the applicable values are displayed
in the table below.
12 In the Text Component Editor dialog box, in the preview pane, select
the DESIGN text. Press Delete.
13 Click the <[Design Speed(P3|RN|Sn|OF|AP)]> property block.
After you have selected the property block in the Preview pane, you can
modify the specific values that will be applied to the property.
14 In the Properties list, select Design Speed. Change the Precision value to
0.1. Click to apply the new Precision value to the block in the Preview
pane.
Notice that in the block of code, P0 has changed to P1.
15 In the Preview pane, select the SPEED text.
16 Click the Format tab.
You can change the style, justification, font, and color of each text
component.
17 With the text in the Preview pane selected, change the Font to Times
New Roman. Click OK.
In the Label Style Composer, notice that the SPEED font is different from
the design speed value. The design speed value font did not change
because it was not selected when you changed the font.
18 Click OK to close the Label Style Composer, Pick Label Style, and
Alignment Labels dialog boxes. Pan along the Main Street alignment to
view the format of the new label style.
Exercise 1: Creating a Label Style | 779
