Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 150

Create a survey network
1 On the Specify Network page, click Create New Network.
2 In the New Network dialog box, for Name, enter Survey Network 1.
3 Click OK.
4 Click Next.
Specify import options
1 On the Import Options page, specify the following parameters:
Current Equipment Database: Sample
Current Equipment: Sample
Show Interactive Graphics: Yes (Selected)
Current Figure Prefix Database: Sample
Process Linework During Import: Yes (Selected)
Current Linework Code Set: Sample
Process Linework Sequence: By Import Order
Assign Offset To Point Identifiers: Yes (Selected)
Point Identifier Offset: 10000
Insert Network Object: Yes (Selected)
Insert Figure Objects: Yes (Selected)
Insert Survey Points: Yes (Selected)
Accept the remaining default values.
2 Click Finish.
The survey data is imported, and the drawing looks like this:
138 | Chapter 6 Survey Tutorials
