Tutorial: Viewing and Editing Survey Data

This tutorial demonstrates how to view and modify survey data in your
drawing.
NOTE Before performing the steps in this tutorial, you must have already set up
the survey database. For more information, see the
You will use the Survey tab in Toolspace to view and manage survey data,
such as points, setups, directions, and figures.
NOTE The Survey Data Collection Link extension can be used to transfer and
convert raw data to an FBK file.
For more information, see the AutoCAD Civil 3D Help topic Adding and Editing
Survey Data.

Exercise 1: Viewing Survey Data

In this exercise, you will use the Toolspace Survey tab and panorama vistas
to view some of the data that you imported from the field book file.
You will also browse to the newly created network and figure objects in the
AutoCAD Civil 3D Prospector tab and drawing.
For more information, see the AutoCAD Civil 3D Help topic The Toolspace
Survey Tab.
View the survey data
NOTE This exercise uses Survey-3.dwg, which you saved in the
Data folder
use the copy of Survey-3.dwg that is in the
you will get duplicate objects when you update the survey data.
1 In Toolspace, on the Survey tab, expand Survey Databases
1 Networks
data, including control points, directions, and setups.
NOTE If you cannot expand the collection, right-click the database name
and click Open For Edit.
2 To view the control points, click the Control Points collection.
The control points are displayed in the Toolspace list view.
144 | Chapter 6 Survey Tutorials
(page 819) during the previous exercise. If you did not do this, you can
Survey Network 1 to display the collections of survey
Survey Setup (page 129) tutorial.
