Profiles Tutorials

These tutorials will get you started viewing and designing the elevation profile of land surfaces
along a horizontal alignment.
NOTE All drawings used in these tutorials are available in the
. If you want to save your work from these tutorials, save the drawings to the
819)
Tutorial Data folder (page 819)
For more information, see the AutoCAD Civil 3D Help topic Understanding the Profile Object.

Tutorial: Designing Simple Profiles

In this tutorial, you will create simple existing ground and layout profiles for
an alignment.
An existing ground profile is extracted from a surface and shows the changes in
elevation along a horizontal alignment. A layout profile is a designed object that
shows the proposed grade and elevations to be constructed. Profiles are displayed
on an annotated grid called a profile view.
so that you do not overwrite the original drawings.
9
tutorial drawings folder (page
My Civil
275
