For more information, see the AutoCAD Civil 3D Help topic Sample Line,
Section, and Section View Labels.
This exercise continues from
View (page 577).
Add a section view grade label
1 Open Sections-Grade-Label.dwg, which is located in the
folder
2 Click Annotate tab
View
The Add Labels dialog box is displayed. You will change the existing
Grade Label Style to show a grade percentage between two points and
the slope length between those points.
3 In the Add Labels dialog box, specify the following parameters:
Label Type: Grade
Grade Label Style: Grade_Slope
4 Click Add.
On the command line, you are prompted to select a section view.
5 In the drawing, click a grid line of the section view.
On the command line, you are prompted to pick a point.
6 In the section view, snap to a low point in the section. Snap to a higher
point "up the hill".
The grade between the two points is displayed. If you wish, add more
grade labels to other pairs of points anywhere in the section view.
7 Right-click or press Esc to end the labeling session.
8 In the Add Labels dialog box, click Close.
To continue this tutorial, go to
View (page 587).

Exercise 3: Adding a Data Band to a Section View

In this exercise, you will add a data band, which is an optional graphic frame
that is associated with the section view.
Exercise 1: Projecting an Object onto a Section
(page 819).
Labels & Tables panel
Add Section View Labels
Exercise 3: Adding a Data Band to a Section
Exercise 3: Adding a Data Band to a Section View | 587
tutorial drawings
Add Labels menu
.
Section
