The First Street Profile view is displayed, containing the dashed profile
that represents the existing ground (EG) surface. The left and right sides
annotate elevations. The bottom annotates the stations.
Create a layout profile
1 Click Home tab
Layers panel
Layer drop-down. Next to the
_PROF-ROAD-FGCL-PL layer, click
.
Tutorial: Designing Simple Profiles | 277
