8 Click Pipe Networks tab
9 In the Network Layout Tools toolbar, click
Two additional tables, called Structures and Pipes are displayed in the
Panorama window.
10 Click the three vista tabs in turn to switch from one table to the other.
Bring the Alignment Entities table to the front.
Rearrange the columns of a vista
1 Scroll to the right until you see the Chord Length column.
2 Click the Chord Length column heading, drag the column to the left,
and drop it to the right of the Length column.
Notice that each column heading is highlighted as the cursor passes
through it. You can rearrange the columns like this to make the table
easier to use.
3 Right-click the Radius column heading. Click Customize Columns.
The Customize Columns dialog box allows you to modify the appearance
of the columns in the current vista. You can hide unnecessary columns
by clearing the appropriate check boxes in the Visibility column, or
change the width of columns using the Width column. Clicking the New
button allows you to save a custom vista configuration for later use.
4 Click Cancel to close the Customize Columns dialog box.
Change the appearance of the Panorama window
1 On the Panorama control bar, click
2 Without clicking, move your pointer over the Panorama control bar.
The window opens while the pointer is on the bar. It closes when you
move the pointer off the vista. This is Auto-Hide Mode, indicated by
. It is useful when you want to periodically consult a table while working
in the drawing.
3 Click
14 | Chapter 2 Getting Started Tutorials
Modify panel
to turn off Auto-Hide Mode.
Edit Pipe Network
.
to temporarily close the window.
.
