2 When prompted, pan to a clear area in the drawing, then click a location
for the profile view origin.
After your sheets are created, the Sheet Set Manager is displayed, showing
the newly created sheets. For more information on the Sheet Set Manager,
see the Sheet Set Manager Help topics in the AutoCAD Help.
3 If the Sheet Set Manager does not open, enter SHEETSET on the command
line.
4 On the Sheet Set Manager, select Open from the drop-down list.
5 On the Open Sheet Set dialog box, navigate to the
folder
On the Sheet Set Manager, notice that the VFG - Maple Road - (1).dst is
open, displaying the five sheets that were created.
6 Select one of the sheets in the list. Right-click and select Open.
The sheet opens as a new drawing.
NOTE You can publish your sheet(s) directly from the Sheet Set Manager or
share them by using the eTransmit feature.
To continue this tutorial, go to

Exercise 2: Creating Section Sheets

In this exercise, you will create sheets from section views.
NOTE To create section views, see the
814 | Chapter 20 Plan Production Tutorials
(page 819) and select VFG - Maple Road.dst. Click Open.
Exercise 2: Creating Section Sheets
My Civil Tutorial Data
Creating Section Views tutorial
(page 814).
