objects that can be projected onto the alignment within the specified
station range.
In this exercise, you will not restrict the quantity report.
Report Selected Pay Items Only: Cleared
4 Click Compute.
5 In the Quantity Takeoff Report dialog box, in the drop-down menu, select
Summary (TXT).xsl.
Examine the report. Notice that the report lists the ID, description, total
quantity, and unit of measure for each pay item.
NOTE The quantities for the pay items that are associated with the corridor
codes are not calculated in a summary report. In the following steps, these
items will be calculated in a itemized report.
6 In the Quantity Takeoff Report dialog box, click Close.
Generate a detailed pay item quantity report
1 In the Compute Quantity Takeoff dialog box, specify the following
parameters:
Report Type: Detailed
Report Extents: Selection Set
Limit Extents To Alignment Station Range: Cleared
Report Selected Pay Items Only: Cleared
Report Station And Offset Relative To: Side Road
In a detailed report, the station and offset value for each item relative
to a specified alignment is displayed.
2 Next to Report Extents, click
3 In the drawing, select the pipes and structures along the side road. Press
Enter.
