Divided highway assembly
For more information, see the AutoCAD Civil 3D Help topic Creating Assemblies.

Exercise 1: Creating an Assembly

In this exercise, you will use some of the subassemblies that are shipped with
AutoCAD Civil 3D to create an assembly for a basic crowned roadway with
travel lanes, curbs, gutters, sidewalks, and slopes to an existing surface.
NOTE The corridor assembly you build will be used to create a corridor model in
the Creating a Basic Corridor
For more information, see the AutoCAD Civil 3D Help topic Creating Assemblies.
Create an assembly baseline
1 Open Assembly-1a.dwg, which is located in the
(page 819).
2 Click Home tab
Assembly
3 In the Create Assembly dialog box, for name, enter Primary Road Full
Section. Click OK.
4 When the 'Specify assembly baseline location' prompt is displayed on
the command line, click in the rectangle under the profile views.
The viewport zooms to the assembly baseline, which looks like this:
422 | Chapter 12 Corridor Assembly Tutorials
(page 472)
(page 459) tutorial.
Create Design panel
.
tutorial drawings folder
Assembly drop-down Create
