Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 61

Verify the point cloud parameters and create the point cloud object
1 On the Summary page, expand the collections in the Property table, and
ensure that the properties match what you specified earlier in this exercise.
If the property values do not match, use the links on the left side of the
dialog box to return to the previous pages.
2 Click Finish.
A dialog box notifies you that the point cloud database is being processed
in the background, and that you may continue to work in the drawing.
3 Click Close.
After a few minutes, a notification appears in the status bar, indicating
that the point cloud database has been processed, and the point cloud
object has been created.
Examine the point cloud object
1 In the status bar notification, click Click Here To Zoom.
The drawing window zooms to the point cloud object.
2 Zoom in until you can see the points that make up the point cloud.
Exercise 1: Importing Point Cloud Data | 49
