MH_Pipe In Invert
MH_Pipe In Material
Clearing the check boxes turns off the display of columns you do not
need to see for this exercise.
4 Click the row for point 307.
5 Click the Point Label Style cell to display the Select Label Style dialog
box.
6 In the Select Label Style dialog box, select Manhole UDP as the label style.
Click OK.
7 Repeat Steps 4 to 6 to apply the Manhole UDP for point 667.
Specify user-defined property values
1 For point 307, click the MH_Pipe In Invert cell. Enter 93.05.
2 Right-click the row for point 307. Click Zoom To.
The value is displayed with the other point information in the drawing
window.
3 For point 667, click the MH_Pipe In Invert cell. Enter 93.00.
4 Right-click the entry for point 667. Click Zoom To.
To continue this tutorial, go to
Properties
Exercise 4: Importing Points with User-Defined
Properties
In this exercise, you will create a custom point file format, and then import
point information that includes user-defined properties from an external file.
For more information, see the AutoCAD Civil 3D Help topic Importing and
Exporting User-Defined Property Classifications.
This exercise continues from
Points (page 41).
42 | Chapter 3 Points Tutorials
Exercise 4: Importing Points with User-Defined
(page 42).
Exercise 3: Assigning User-Defined Properties to
