Change the style of a point group
NOTE This exercise uses Points-2.dwg and Existing Basemap.dwg with the
modifications you made in the previous exercise.
1 Zoom in to the upper left area of the screen where you can clearly see
the labels for several POND points and one or more STORM MH points.
Notice that both types of points use the same marker style (X).
2 In Toolspace, on the Prospector tab, right-click the point group _All
Points. Click Properties.
3 In the Point Group Properties dialog box, on the Information tab, change
the Point Label Style to <none>.
4 Click OK.
Labels for all points that do not have a label style set in another point
group are hidden. The point markers are still visible because markers are
controlled by the point style, which you did not change.
5 In Toolspace, on the Prospector tab, right-click the point group Storm
Manholes. Click Properties.
6 In the Point Group Properties dialog box, on the Information tab, change
the Point Style to Storm Sewer Manhole.
7 Click OK.
The stormwater manhole points are now marked with the symbol defined
in the Storm Sewer Manhole point style.
To continue this tutorial, go to
Order (page 33).

Exercise 3: Changing Point Group Display Order

In this exercise, you will use the point group display order to change the
appearance of points.
For more information, see the AutoCAD Civil 3D Help topic Changing the Point
Group Display Order.
Exercise 3: Changing Point Group Display
Exercise 3: Changing Point Group Display Order | 33
