Exercise 5: Viewing Pipe Network Parts in a Section View

In this exercise, you will view the pipe network parts in a section view.
For more information, see the AutoCAD Civil 3D Help topic Displaying Pipe
Networks in Section Views.
This exercise continues from
Part in a Profile View
Create a sample line
NOTE This exercise uses Pipe Networks-3B.dwg with the modifications you made
in the previous exercise, or you can open Pipe Networks-3C from the
drawings folder
1 In the drawing, zoom to the area around station 12+60 on the ROAD1
alignment.
2 Click Home tab
3 Press Enter when prompted to select an alignment.
4 In the Select Alignment dialog box, select ROAD1. Click OK.
5 In the Create Sample Line Group dialog box, click OK.
6 On the command line, enter 1260.
7 For the left swath width, enter 20.
8 For the right swath width, enter 20.
The sample line is created at the specified station.
9 Press Enter to end the sample line creation command.
Create a section view
1 Click Home tab
drop-down
2 In the Create Section View wizard, click Section Display Options.
3 On the Section Display Options page, in the Select Sections To Draw list,
in the ROAD1_SURF row, click the Change Labels cell.
4 In the Select Style Set dialog box, select No Labels. Click OK.
652 | Chapter 17 Pipe Network Tutorials
Exercise 4: Overriding the Style of a Pipe Network
(page 650).
(page 819).
Profile & Section Views panel
Profile & Section Views panel
Create Section View
tutorial
Sample Lines
Section Views
.
.
