20 Make the following additional edits:
SBH SRS-SFH-SCH
SBPC 3.0
SBSD SID+(2*Wth)
SBSH SRS+FTh
21 Edit the Equations and Descriptions for the LenA# parameters as shown
in the following table:
LenA1 SFH
LenA2 SCH
LenA3 SVPC-SFH-SCH+(BdyD5/2)
LenA4 SRS+FTh-SFH-SCH-LenA3-LenA5
LenA5 24
LenA6 (SID/2)+WTh+(BdyD5/2+2)
Click Close. Change to SE Isometric view and note the changes to the
geometry of the structure.
22 Change the 4 circular profiles so they are not visible by right-clicking on
each and then clicking Visible.
The circular profiles are no longer visible.
23 Repeat the previous step for all of the Dimensions.
24 Change view to SE Isometric and examine the part. It should look like
the following image.
Exercise 3: Creating Profiles and Establishing Parameters | 699
Frame Cylinder Height
Cone Cylinder Height
Top Pipe CL
Top Pipe CL to Bottom Pipe CL
Bottom Pipe CL to Struct Bottom
CL Vert Pipe to Incoming Pipe
