Change a profile style
1 Select the PV - (1) profile view grid. Right-click. Click Profile View
Properties.
2 Click the Profiles tab.
On this tab, you can change properties of a profile line after it has been
drawn in a profile view.
3 On the Profiles tab, scroll until you can see the Style and Override Style
columns.
4 In the Override Style column for the Left Offset, double-click the check
box.
5 In the Pick Profile Style dialog box, select Existing Ground. Click OK.
6 In the Profile View Properties dialog box, click Apply.
The Left Offset profile changes to red (reflecting the Existing Ground
style) in profile view PV - (1), but not in PV - (2). The left offset profiles
are different because you overrode the profile style for the particular
284 | Chapter 9 Profiles Tutorials
