Tutorial: Outputting Survey Information; Exercise 1: Viewing Inverse And Mapcheck Information On A Survey Figure - Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual

2 In Toolspace, on the Survey tab, right-click Survey Databases. Click New
Local Survey Database.
3 In the New Local Survey Database dialog box, for the name, enter Survey
5. Click OK.
Create survey figures from existing parcels
1 In Toolspace, on the Survey tab, expand the database Survey 5. Right-click
the Figures collection. Click Create Figure From Object.
2 In the drawing, click the label for the parcel SINGLE-FAMILY: 101.
3 In the Create Figure From Objects dialog box, specify the following
parameters:
Name: LOT CORNER
Current Figure Prefix Database: Sample
Associate Survey Points To Vertices: Yes
4 Click OK.
5 Press Esc to end the command.
The figure is created and added to the survey database. Information about
the figure is displayed in list view.
To continue to the next tutorial, go to
171).

Tutorial: Outputting Survey Information

This tutorial demonstrates how to view information reports for figures and
how to use the figures as a source for surface data.
For more information, see the AutoCAD Civil 3D Help topics Figure Inquiry
Commands and Creating Breaklines from Figures.
Exercise 1: Viewing Inverse and Mapcheck Information
on a Survey Figure
In this exercise, you will display the figure mapcheck and inverse information.
Outputting Survey Information
Tutorial: Outputting Survey Information | 171
(page
