4 In the Apply Feature Line Names dialog box, place the cursor at the
beginning of the Name field. Enter ABC.
The Name field should contain
Click OK.
5 In Toolspace, on the Prospector tab, expand Sites
Feature Lines collection.
Notice that the two feature lines and their names are displayed in the
Prospector list view.
Next, you will draw a feature line and specify elevations along the line.
Draw a feature line
1 Click Home tab
drop-down
2 In the Create Feature Lines dialog box, specify the following parameters:
Name Check Box: Selected
Name: CDEF <[Next Counter]>
Style Check Box: Selected
Style: Ditch
3 In the Create Feature Lines dialog box, click OK.
4 In the drawing window, snap to the end of the feature line inside circle
C. When prompted, enter 688.00 as the elevation.
You have entered a known value for the starting elevation. In the
following steps, you will use the transition command to defer entering
elevation values at intermediate points along the feature line.
5 Stretch the feature line and click inside circle D. When prompted for an
elevation, enter T.
6 Stretch the feature line and click inside circle E. When prompted for an
elevation, press Enter to accept Transition.
7 Stretch the feature line and click inside circle F. When prompted for a
transition, enter SU to use the elevation of the surface at that point.
8 Note the surface elevation shown at the command line. Press Enter twice
to accept the elevation and end the command.
394 | Chapter 11 Grading Tutorials
ABC <[Next Counter]>
Create Design panel
Create Feature Line
.
Site 1. Select the
Feature Line
.
